Single Stage High Discharge coolant pumps (MPS Series)



POWERPOINT is a leading Manufacturers, Suppliers and Exporters of HI Descharge Coolant Pumps(MPS) in Kolkata, West Bengal, India



FEATURES :-



  • Available in very wide range.
  • High  of design.
  • Availability in any type of material like cast iron,SS-316,SS-304,bronze,Alloy – 20 Etc..
  • Balanced shaft & rotor with excellent grade stamping and wire so highly efficient motor .
  • Totally noiseless operation.
  • Available in any length and for any liquid.
  • Extruded powder coated motor body (up to 1 HP ) .
  • No shaft seal( 100 % Maintenance free      ).
  •  Closed and Semi open impellers (ensure free passage of solids and chips)
  • Large stock, earliest delivery.

WIDE RANGE OF APPLICATION:-



Turning Grinding Granite
Boring Filtration Fountains
Drilling Circulation Washing
Milling Printing Heat treatment
Cutting Conveyor  Oil Transfer
Sawing Cooling





PERFORMANCE CHART OF MPS SERIES

MODEL

Outlet Size

KW/HP

Head in meters VS LPM

7

9

11

13

15

17

19

21

23

25

27

30

MPS-101

25 mm

0.37 KW / 0.50 HP

-

100

86

80

40

-

-

-

-

-

-

-

MPS-103

40 mm

0.75 KW / 1.0 HP

240

205

145

-

-

-

-

-

-

-

-

-

MPS-106

40 mm

0.75 KW / 1.0 HP

-

255

240

230

215

200

165

95

-

-

-

-

MPS-108

50 mm

0.75 KW / 1.0 HP

415

375

302

225

-

-

-

-

-

-

-

-

MPS-109

40 mm

1.1 KW / 1.50 HP

-

220

210

205

195

183

170

160

140

110

72

-

MPS-114

50 mm

1.5 KW / 2 HP

-

410

395

365

348

308

270

215

148

-

-

-

MPS-116

80 mm

1.5 KW / 2 HP

815

745

670

600

485

373

-

-

-

-

-

-































PERFORMANCE CHART OF MPS SERIES

MODEL

Outlet Size

KW/HP

Head in meters VS LPM

10

12

14

16

18

20

22

24

26

28

 30 32 34 36 40 44 46 48 52

MPS-325

50 mm

2.2 KW / 3 HP

-

552

528

504

474

444

420

384

348

294

-

-

-

-

-

-

-

-

-

-

MPS-335

40 mm

2.2 KW / 3 HP

-

-

300

294

 288

282

276

264

252

240

228

216

192

162

120

-

-

-

-

-

MPS-538

50 mm

3.7 KW / 5 HP

-

-

-

-

-

510

498

468

456

426

348

-

-

-

-

–

-

-

-

-

MPS-550

40 mm

3.7 KW / 5 HP

-

-

-

-

-

-

-

-

-

-

-

516

-

486

450

408

 354

270

222

MPS-852

50 mm

5.5KW/7.5 HP

-

-

-

-

-

-

-

-

-

516

486

450

408

354

270

222

-

-

-

-

MPS-830

65 mm

5.5KW/7.5 HP

-

-

-

-

1140

1092

1038

984

924

852

780

666

-

-

-

-

-

-

-

-
